Link-Belt TQP2506 Take-up Frames Bearing Parts & Kits - TQP2506
Part #:10430665
Catalog #:TQP2506
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Travel Length (in): | 6 in | Adjusting Screw Thread Size (in): | 3/4 - 10 NC in |
| Maximum Mounting Plate Bolt Hole Spacing (in): | 5 11/16 in | Frame Type: | Quick-Release T-Frame Protected Screw Take-Up |
| Mounting Plate Bolt Size (in): | 1/2 in | Minimum Mounting Plate Bolt Hole Spacing (in): | 3 13/16 in |
| Mounting Plate Width (in): | 2 1/32 in | Take-up Frame Assembly Type: | Quick-Release T-Frame Protected Screw Take-Up |
| Mounting Plate Length (in): | 7 in | Frame Length (in): | 11 1/2 in |
| Product: | TQP Take-up Frames | Adjusting Screw Square Drive (in): | 1/2 in |
| Frame Height (in): | 4 7/8 in | Series: | TQP Take-up Frames |
| Centerline of Frame to Bottom of Mounting Pad (in): | 1 in | Distance from End of Adjustment Screw to Latch Support (in): | 1 9/16 in |
General Specifications
| UPC: | 662327983420 | Weight: | 7.00 LB |
