Rexnord ZD2400 Duplex Units Rex Spherical Roller Bearings - ZD2400
Part #:10443362
Catalog #:ZD2400
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Dimensions
| Bore Diameter (in): | 4 in |
Technical Specifications
| Radial Dynamic Load Capacity (lb): | 130,970 lb | Series: | Duplex Units |
| Static Load Rating (lb): | 137,000 lb | Product: | ZD2000 |
| Fixed/Expansion: | Fixed | Housing Style: | Duplex Unit |
| Housing Material: | Cast Iron | Housing Type: | Duplex Unit |
| Housing Color: | Black | Housing Construction: | Solid |
| Shaft Locking Type: | Single Set Collar | Cage Material: | Engineered Polymer |
| Maximum Speed (RPM): | 2050 rpm | Available Seal Type: | K Light Contact Lip Seal; M Spring Loaded Heavy Contact Lip Seal (Buna and Viton); Z Clearance Seal; G Triple Lip |
| Vibration Frequency Inner Ring Defect: | 0.1717 cps | Vibration Frequency Outer Ring Defect: | 0.1283 cps |
| Vibration Frequency Roller Spin: | 0.0548 cps | Insert: | 2400U |
| Vibration Frequency Fundamental Train: | 0.0071 cps | Locking Device Kit: | SC11 |
| Primary Seal: | STEEL CLEARANCE SEAL | Size Code: | 11 |
| Housing Coating: | POWDER COATED |
General Specifications
| UPC: | 698210711122 | Weight: | 30.50 LB |
| Packaged Length: | 9.69 IN | Packaged Width: | 9.69 IN |
| Packaged Height: | 6.25 IN | Country of Origin: | Mexico |
