Rexnord ZMC9600 Cartridge Blocks Rex Spherical Roller Bearings - ZMC9600
Part #:10426487
Catalog #:ZMC9600
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Dimensions
| Overall Width (in): | 7.75 in | Housing Width (in): | 6.19 in |
| Overall Length (in): | 13.56 in | Bore Diameter (in): | 6 in |
| Slot Length (in): | 1.5 in | Overall Height (in): | 13.56 in |
| Slot Width (in): | 0.75 in | Outside Diameter (in): | 13.563 in |
| Housing Width with Extension (in): | 6.5 in | Locking Collar Outside Diameter (in): | 9.06 in |
| Slot Depth (in): | 0.22 in | Housing Outside Step Diameter (in): | 11.38 in |
| Centerline to Outermost Bearing Face (in): | 4.78 in | Housing Cast Face to Outermost Bearing Face (in): | 1.69 in |
| Length Through Bore (in): | 7.75 in | Inner Ring Outside Diameter (in): | 8.046 in |
Technical Specifications
| Seal Type: | Clearance Seal | Static Load Rating (lb): | 395,500 lb |
| Cage Material: | Steel | Radial Dynamic Load Capacity (lb): | 309,860 lb |
| Rolling Element: | Spherical Roller | Series: | Cartridge Blocks |
| Product: | ZMC9000 | Shaft Locking Type: | Adapter Mount |
| Fixed/Expansion: | Fixed | Housing Construction: | Solid |
| Radial Clearance: | C3 STANDARD | Misalignment Type: | Dynamic |
| Housing Material: | Cast Iron | Housing Style: | Cartridge Block |
| Seal Kit: | ZS16NEW | Ability to Relubricate: | Yes |
| Available Seal Type: | M Spring Loaded Heavy Contact Lip Seal (Buna and Viton); Z Clearance Seal | Maximum Speed (RPM): | 800 rpm |
| Shaft Locking Collar Kit/Adapter Assembly: | AK16600 | Size Code: | 16 |
| Primary Seal: | STEEL CLEARANCE SEAL | Max Operating Temperature (F): | 225 °F |
| Vibration Frequency Outer Ring Defect: | 0.1271 cps | Vibration Frequency Inner Ring Defect: | 0.1729 cps |
| Vibration Frequency Roller Spin: | 0.0521 cps | Insert: | 9600U |
| Vibration Frequency Fundamental Train: | 0.0071 cps | Grease Fitting Thread Size: | 1/4 NPT |
| Lubricant: | Lithium Complex NLGI 2 Grease | Locking Device Kit: | AK16600 |
| Max Operating Temperature (C): | 107 °C | Misalignment Capability: | ±2.0° Misalignment - Dynamic |
General Specifications
| UPC: | 698210714246 | Weight: | 177.00 LB |
| Packaged Length: | 13.00 IN | Packaged Width: | 10.00 IN |
| Packaged Height: | 13.00 IN |
