Link-Belt MA1211EX Unmounted Bearings Cylindrical Roller Bearings - MA1211EX
Part #:10471309
Catalog #:MA1211EX
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Dimensions
| Bore Size (mm): | 11 - 55 mm | Outside Diameter (mm): | 100 mm |
Technical Specifications
| Inner Ring Bore Radius (mm): | 1.52 mm | Inner Ring Type: | Plain Cylindrical (A) |
| Series Weight: | Light (2) | Rolling Element: | Cylindrical |
| Co Static Load Rating: | CALL ENG lb | Retainer Type: | SEE DESCRIPTION |
| Shaft Locking: | DIRECT SHAFT MOUNT | Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm): | 91.4 mm |
| Vibration Frequency Inner Ring Defect: | CALL ENG cps | Vibration Frequency Fundamental Train: | CALL ENG cps |
| Product: | Series 1200 Unmounted Bearings | Series: | Unmounted Bearings |
| Vibration Frequency Outer Ring Defect: | CALL ENG cps | Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm): | 64 mm |
| Outer Ring Type: | Double Rib Outer Ring (E) | Inner Ring and Roller Assembly Over Roller Diameter (mm): | 87.96 mm |
| Ring Width Series: | Narrow (1) | Inner Ring Raceway Outside Diameter (mm): | 66.9 mm |
| Basic Bearing Number: | 1211 | Inner Ring Rib Outside Diameter (mm): | 70.74 mm |
| Bearing Width (mm): | 21 mm | Outer Ring Raceway Inside Diameter (mm): | 88.02 mm |
| Mounted Clearance: | SEE DESCRIPTION | Vibration Frequency Roller Spin: | CALL ENG cps |
| Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm): | 87.9 mm | Outer Ring Rib Inside Diameter (mm): | 84.53 mm |
| Maximum Speed (RPM): | CALL ENG rpm | C Dynamic Load Rating: | CALL ENG lb |
| Outer Ring and Roller Assembly Under Roller Diameter (mm): | 66.96 mm | Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm): | 66.8 mm |
General Specifications
| UPC: | 662327051709 | Weight: | 1.58 LB |
| HTC: | 8482500000 | Country of Origin: | Mexico |
