Link-Belt MA6214TV Unmounted Bearings Cylindrical Roller Bearings - MA6214TV
Part #:10471253
Catalog #:MA6214TV
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Dimensions
| Bore Size (mm): | 70 mm | Outside Diameter (mm): | 125 mm |
Technical Specifications
| Shaft Shoulder Diameter [Min] (mm): | 81.8 mm | Maximum Speed (RPM): | CALL ENG rpm |
| Vibration Frequency Inner Ring Defect: | CALL ENG cps | Series: | Unmounted Bearings |
| Mounted Clearance: | SEE DESCRIPTION | C Dynamic Load Rating: | CALL ENG lb |
| Rolling Element: | Cylindrical | Retainer Type: | SEE DESCRIPTION |
| Bearing Width (mm): | 79.38 mm | Ring Width Series: | Double Row (6) |
| Outer Ring Raceway Inside Diameter (mm): | 111.54 mm | Bore Type: | Straight |
| Co Static Load Rating: | CALL ENG lb | Vibration Frequency Outer Ring Defect: | CALL ENG cps |
| Outer Ring Type: | Outer Ring With Two Retaining Rings in I.D. (T) | Basic Bearing Number: | 6214 |
| Housing Shoulder Diameter [Min] (mm): | 115.60 mm mm | Series Weight: | Light (2) |
| Outer Ring and Roller Assembly Under Roller Diameter (mm): | 84.84 mm | Inner Ring Type: | Plain Cylindrical (A) |
| Vibration Frequency Roller Spin: | CALL ENG cps | Inner Ring Raceway Outside Diameter (mm): | 84.77 mm |
| Inner Ring Bore Radius (mm): | 1.52 mm | Product: | Series 6200 Unmounted Bearings High Capacity |
| Shaft Locking: | DIRECT SHAFT MOUNT | Vibration Frequency Fundamental Train: | CALL ENG cps |
General Specifications
| UPC: | 662327054045 | Weight: | 10.18 LB |
| HTC: | 8482500000 | Country of Origin: | Mexico |
