Link-Belt MR1210UV Unmounted Bearings Cylindrical Roller Bearings - MR1210UV
Part #:10472410
Catalog #:MR1210UV
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Dimensions
| Bore Size (mm): | 10 - 50 mm | Outside Diameter (mm): | 90 mm |
Technical Specifications
| Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm): | 79.5 mm | Series: | Unmounted Bearings |
| Outer Ring Type: | Single Rib Outer Ring One Retaining Ring in I.D. (U) | Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm): | 82.8 mm |
| Outer Ring Raceway Inside Diameter (mm): | 79.55 mm | Shaft Locking: | DIRECT SHAFT MOUNT |
| Co Static Load Rating: | CALL ENG lb | Vibration Frequency Roller Spin: | CALL ENG cps |
| Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm): | 60.4 mm | Vibration Frequency Outer Ring Defect: | CALL ENG cps |
| Inner Ring Raceway Outside Diameter (mm): | 60.46 mm | Vibration Frequency Inner Ring Defect: | CALL ENG cps |
| Basic Bearing Number: | 1210 | Vibration Frequency Fundamental Train: | CALL ENG cps |
| Retainer Type: | SEE DESCRIPTION | Product: | Series 1200 Unmounted Bearings |
| Outer Ring Rib Inside Diameter (mm): | 76.66 mm | Ring Width Series: | Narrow (1) |
| Outer Ring and Roller Assembly Under Roller Diameter (mm): | 60.51 mm | Inner Ring and Roller Assembly Over Roller Diameter (mm): | 79.49 mm |
| Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm): | 57.6 mm | Inner Ring Rib Outside Diameter (mm): | 63.96 mm |
| Inner Ring Type: | Single Rib (R) | Mounted Clearance: | SEE DESCRIPTION |
| Inner Ring Bore Radius (mm): | 1.02 mm | Rolling Element: | Cylindrical |
| C Dynamic Load Rating: | CALL ENG lb | Maximum Speed (RPM): | CALL ENG rpm |
| Bearing Width (mm): | 20 mm | Series Weight: | Light (2) |
General Specifications
| UPC: | 662327054403 | Weight: | 1.14 LB |
| HTC: | 8482500000 | Country of Origin: | Mexico |
