Link-Belt MU1209RUM Unmounted Bearings Cylindrical Roller Bearings - MU1209RUM
Part #:10472971
Catalog #:MU1209RUM
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Dimensions
| Bore Size (mm): | 45 mm | Outside Diameter (mm): | 85 mm |
Technical Specifications
| Series Weight: | Light (2) | Outer Ring Type: | Single Rib Outer Ring One Retaining Ring in I.D. (U) |
| Series: | Unmounted Bearings | Shaft Locking: | DIRECT SHAFT MOUNT |
| Vibration Frequency Outer Ring Defect: | CALL ENG cps | Maximum Speed (RPM): | CALL ENG rpm |
| Inner Ring and Roller Assembly Over Roller Diameter (mm): | 74.94 mm | Product: | Series 1200 Unmounted Bearings |
| Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm): | 55.4 mm | Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm): | 74.9 mm |
| Co Static Load Rating: | CALL ENG lb | Inner Ring Type: | Double Rib (U) |
| Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm): | 78.2 mm | C Dynamic Load Rating: | CALL ENG lb |
| Vibration Frequency Inner Ring Defect: | CALL ENG cps | Mounted Clearance: | SEE DESCRIPTION |
| Vibration Frequency Roller Spin: | CALL ENG cps | Basic Bearing Number: | 1209 |
| Bearing Width (mm): | 19 mm | Vibration Frequency Fundamental Train: | CALL ENG cps |
| Retainer Type: | SEE DESCRIPTION | Outer Ring Raceway Inside Diameter (mm): | 74.99 mm |
| Outer Ring Rib Inside Diameter (mm): | 71.8 mm | Inner Ring Raceway Outside Diameter (mm): | 55.52 mm |
| Inner Ring Bore Radius (mm): | 1.52 mm | Inner Ring Rib Outside Diameter (mm): | 59.03 mm |
| Rolling Element: | Cylindrical | Ring Width Series: | Narrow (1) |
| Outer Ring and Roller Assembly Under Roller Diameter (mm): | 55.57 mm | Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm): | 52.8 mm |
General Specifications
| UPC: | 662327056971 | Weight: | 1.08 LB |
| HTC: | 8482500000 | Country of Origin: | Mexico |
