Link-Belt MU5214UM Unmounted Bearings Cylindrical Roller Bearings - MU5214UM
Part #:10470995
Catalog #:MU5214UM
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Dimensions
| Bore Size (mm): | 14 - 70 mm | Outside Diameter (mm): | 125 mm |
Technical Specifications
| Vibration Frequency Outer Ring Defect: | CALL ENG cps | Shaft Locking: | DIRECT SHAFT MOUNT |
| Inner Ring Bore Radius (mm): | 1.52 mm | Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm): | 84.6 mm |
| Inner Ring Raceway Outside Diameter (mm): | 84.77 mm | Outer Ring Raceway Inside Diameter (mm): | 111.54 mm |
| Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm): | 81.8 mm | Outer Ring and Roller Assembly Under Roller Diameter (mm): | 84.84 mm |
| Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm): | 111.5 mm | Inner Ring Rib Outside Diameter (mm): | 89.61 mm |
| Product: | Series 5200 Unmounted Bearings | Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm): | 115.6 mm |
| Outer Ring Rib Inside Diameter (mm): | 107.01 mm | Ring Width Series: | Wide (5) |
| Vibration Frequency Roller Spin: | CALL ENG cps | Maximum Speed (RPM): | CALL ENG rpm |
| Basic Bearing Number: | 5214 | Series Weight: | Light (2) |
| Vibration Frequency Fundamental Train: | CALL ENG cps | Co Static Load Rating: | CALL ENG lb |
| C Dynamic Load Rating: | CALL ENG lb | Inner Ring Type: | Double Rib (U) |
| Vibration Frequency Inner Ring Defect: | CALL ENG cps | Series: | Unmounted Bearings |
| Inner Ring and Roller Assembly Over Roller Diameter (mm): | 111.47 mm | Retainer Type: | SEE DESCRIPTION |
| Bearing Width (mm): | 39.69 mm | Mounted Clearance: | SEE DESCRIPTION |
| Rolling Element: | Cylindrical | Outer Ring Type: | Single Rib Outer Ring One Retaining Ring in I.D. (U) |
General Specifications
| UPC: | 662327059194 | Weight: | 4.70 LB |
| HTC: | 8482500000 | Country of Origin: | Mexico |
