Link-Belt ER15 Unmounted Replacement Bearings Ball Bearings - ER15
Part #:10431484
Catalog #:ER15
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Dimensions
| Bore Size (in): | 0.9375 in | Outer Race OD (in): | 2.0472 in |
| Length Through Bore (in): | 1.371 in | Outer Race Width (in): | 0.749 in |
| Outer Race OD (mm): | 52 mm | Outer Race Width (mm): | 19.1 mm |
| Inner Ring OD (in): | 1.313 in | Overall Width (in): | 1.37 in |
Technical Specifications
| Misalignment Type: | Static Only | Vibration Frequency Fundamental Train: | 0.0067 cps |
| Bore Shape: | Straight | Ability to Relubricate: | Yes |
| Outer Race Profile: | Cylindrical | Snap Ring Width (in): | 0.05 in |
| Outer Ring Land Profile: | Standard | Snap Ring Outside Diameter (in): | 2.27 in |
| Size Code: | 205 | Setscrew Torque (in-lbs): | 87-92 in/lbs |
| Distance from Inner Ring Long Hub Face to Centerline of Setscrew (in): | 0.23 in | Housing Type: | Insert (ER Style) |
| Precision Rating: | ABEC 1 | Inner Ring Fillet Radius (in): | 0.04 in |
| Rolling Element: | Ball Bearing | Available Seal Type: | N Lip Seal;E1 Viton Seal;FF Free Running;HFF Free Running;MHFF Free Running;NFF Lip Seal w/ Flinger |
| Internal Clearance: | C3 STANDARD | Short Hub Length (in): | 0.51 in |
| Distance from Outer Ring Face to Snap Ring Face (in): | 0.09 in | Misalignment: | None |
| Set Screw Thread: | 1/4-28 UNF | Lubrication Type: | EXXON RONEX MP STD |
| Series: | Unmounted Replacement Bearings | Vibration Frequency Roller Spin: | 0.0387 cps |
| Locking Type: | Set Screw | Product: | ER |
| Duty/Status: | Standard | Maximum Operating Temperature (F): | 225 °F |
| End Cap: | No | Vibration Frequency Inner Ring Defect: | 0.0905 cps |
| Cage Material: | Molded fiber glass reinforced nylon | Inner Race Profile: | Wide Inner Ring |
| Vibration Frequency Outer Ring Defect: | 0.0595 cps | Primary Seal: | BUNA SINGLE LIP CONTACT SEAL |
| Expansion: | No | Maximum Speed (rpm): | 9600 rpm |
| Bearing Insert Coating: | Black Oxide | Seal Type: | Single Lip Contact Seal |
| Insert Material: | 52100 Bearing Steel | Maximum Operating Temperature (C): | 107 °C |
| Static Load Rating (lb): | 1,760 lb | Dynamic Load Rating (lb): | 3,150 lb |
| Cage Type: | Ball Riding Retainer |
General Specifications
| UPC: | 662864001717 | Weight: | 0.58 LB |
| Packaged Length: | 2.50 IN | Packaged Width: | 2.50 IN |
| Packaged Height: | 1.50 IN | HTC: | 8482105048 |
| Country of Origin: | Mexico |
