Link-Belt 22222LBC0 Bearing Inserts (Unmounted Replacements) Link-Belt Spherical Roller Bearings - 22222LBC0
Part #:10437430
Catalog #:22222LBC0
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Dimensions
| Bore Size (mm): | 110 mm | Bore Size (in): | 3.9370 in |
Technical Specifications
| Bore Type: | Straight | Maximum Speed Using Oil (RPM): | 2500 rpm |
| Vibration Frequency Fundamental Train: | 0.0069 cps | Maximum Speed Using Grease (RPM): | 2000 rpm |
| Retainer Type: | Steel | Housing Fillet Radius (in): | 0.08 in |
| Bearing Type: | SPHERICAL ROLLER BRG | Mounted Clearance: | C0 NORMAL |
| C Dynamic Load Rating: | 102000 lb | Size Code: | 22222 |
| Locking Type: | Direct Shaft Mount | Sealed: | None |
| Co Static Load Rating: | 132000 lb | Maximum Speed (RPM): | 2000 GREASE - 2500 OIL rpm |
| Vibration Frequency Inner Ring Defect: | 0.1650 cps | Vibration Frequency Outer Ring Defect: | 0.1186 cps |
| Vibration Frequency Roller Spin: | 0.0493 cps | Outside Diameter (in): | 7.874 in |
| Bearing Brand: | LINK-BELT SPHER SPLIT BLKS TU | Maximum Shoulder Diameter (in): | 7.40 in |
| Product: | 22200LB | Minimum Shoulder Diameter (in): | 4.80 in |
General Specifications
| UPC: | 662327408893 | Weight: | 15.63 LB |
| HTC: | 8482300080 | Country of Origin: | Japan |
