Link-Belt A22196S Bearing Inserts (Unmounted Replacements) Link-Belt Spherical Roller Bearings - A22196S
Part #:10436092
Catalog #:A22196S
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Dimensions
| Bore Size (in): | 1.9680 in |
Technical Specifications
| Product: | A20000S | Housing Fillet Radius (in): | 0.078 in |
| Maximum Shoulder Diameter (in): | 3.18 in | Bearing Brand: | LINK-BELT A SPHER RLR BRGS |
| Sealed: | None | Co Static Load Rating: | 16600 lb |
| Service Instructions: | BR3-006 LINK-BELT A SERIES | C Dynamic Load Rating: | 12400 lb |
| Apex Distance: | 0.024 in | Outer Ring Width (in): | 0.6510 in |
| Maximum Speed (RPM): | 4500 rpm | Vibration Frequency Fundamental Train: | CALL ENG cps |
| Bore Length (in): | 0.787 in | Bearing Type: | SPHERICAL ROLLER BRG |
| Retainer Type: | Steel | Outside Diameter (in): | 3.5433 in |
| Fixed vs. Expansion: | Fixed | Vibration Frequency Roller Spin: | CALL ENG cps |
| Vibration Frequency Outer Ring Defect: | CALL ENG cps | Locking Type: | Direct Shaft Mount |
| Inner Ring Bore Radius (in): | 0.078 in | Minimum Shoulder Diameter (in): | 2.38 in |
| Vibration Frequency Inner Ring Defect: | CALL ENG cps | Bore Type: | Straight |
General Specifications
| UPC: | 662327004514 | Weight: | 1.18 LB |
| Packaged Length: | 3.69 IN | Packaged Width: | 3.69 IN |
| Packaged Height: | 2.13 IN | Country of Origin: | Mexico |
