Link-Belt MSLN8 Unmounted Replacement Bearings Ball Bearings - MSLN8
Part #:10421468
Catalog #:MSLN8
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Dimensions
| Bore Size (in): | 0.5000 in |
Technical Specifications
| Locking Type: | Set Screw | Bearing Type: | Standard Duty |
| Vibration Frequency Outer Ring Defect: | 0.0428 cps | Vibration Frequency Roller Spin: | 0.0293 cps |
| Bearing Brand: | LINK-BELT 200 SERIES BALL | Maximum Speed (RPM): | 14000 rpm |
| Primary Seal: | BUNA SINGLE LIP CONTACT SEAL | C Dynamic Load Rating: | 2360 lb |
| Vibration Frequency Fundamental Train: | 0.0062 cps | Setscrew Torque (in-lbs): | 35 in/lbs |
| Mounted Clearance: | C3 STANDARD | Service Instructions: | BR3-007 LB 200 BALL-300 BALL |
| Vibration Frequency Inner Ring Defect: | 0.0738 cps | Co Static Load Rating: | 1110 lb |
| Product: | MSLN | Retainer Type: | NYLON |
| Lubrication Type: | EXXON RONEX MP STD | Size Code: | 203 |
General Specifications
| UPC: | 662864005692 | Weight: | 0.22 LB |
| Packaged Length: | 2.50 IN | Packaged Width: | 2.50 IN |
| Packaged Height: | 1.50 IN | HTC: | 8482105048 |
| Country of Origin: | Mexico |
