Rexnord 5930 Series Solid One Piece Molded Acetal Sprocket with 24 Teeth and a 1-1/4in Round Shaft-Ready Bore with Keyway & 2 Setscrews - 114-699-3
Part #:10028488
Catalog #:114-699-3
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Sprocket Construction: | Molded Non-Split Sprocket | Product Group: | MatTop® |
| Bore Type: | Shaft-Ready | Bore Diameter (in): | 1-1/4 in |
| Number of Teeth: | 24 | Pitch Diameter (in): | 5.746 |
| Product Line: | Chain and Belt Sprockets | Chain Number: | 5930 |
| Bore Shape: | Round | Number of Keyways: | 1 |
| Material: | Acetal | Body Style: | Block |
| Pitch Diameter (mm): | 145.95 | Sprocket Series: | 5930 |
| Number of Set Screws: | 2 Setscrews |
General Specifications
| UPC: | 698210856847 | Weight: | 0.48 LB |
| Packaged Length: | 7.00 IN | Packaged Width: | 7.00 IN |
| Packaged Height: | 3.00 IN | HTC: | 8483901050 |
| Country of Origin: | Mexico |
