Rexnord 815 Series Split Molded Nylon Sprocket and a 25 Teeth with 1-3/16in Round Shaft-Ready Bore with Keyway & Setscrew - 614-31-2
Part #:10028616
Catalog #:614-31-2
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Number of Teeth: | 25 | Body Style: | Block |
| Pitch Diameter (mm): | 151.99 | Bore Type: | Shaft-Ready |
| Sprocket Series: | 815 | Sprocket Construction: | Molded Split Sprocket |
| Material: | Nylon | Bore Diameter (in): | 1-3/16 in |
| Product Group: | TableTop® | Product Line: | Chain and Belt Sprockets |
| Number of Keyways: | 1 | Chain Number: | 815 |
| Pitch Diameter (in): | 5.984 | Bore Shape: | Round |
| Number of Set Screws: | 1 Setscrew |
General Specifications
| UPC: | 698210858544 | Weight: | 1.20 LB |
| Packaged Length: | 7.00 IN | Packaged Width: | 7.00 IN |
| Packaged Height: | 3.00 IN | HTC: | 8483901050 |
| Country of Origin: | Mexico |
