Rexnord 7956GT Side-flexing Flush Grid, Material: Brown High Performance, Width: 24in, Pitch: 1.25in - 10324712
Part #:10324712
Catalog #:10324712
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Belt Thickness (in): | 0.5 in | Straight or Side-Flex: | Side-flexing |
| Chain Width (in): | 24 in | Chain Material Description: | Brown High Performance |
| Series: | MatTop 7956 Series Side-flexing Chain | Surface Type: | Flush Grid |
| Curve Retention Type: | GT | Direction: | Counterclockwise |
| Chain Strength (lb): | 1,000 lb | Open Area (%): | 16 % |
| Chain Width Measurement System: | Imperial | Belt Thickness (mm): | 12.7 mm |
| Chain Number: | 7956GT | Chain Material: | HP |
| Chain Strength (N): | 4,440 N | Chain Pitch (mm): | 31.75 mm |
| Chain Pitch (in): | 1.25 in | Chain Width (mm): | 609.6 mm |
| Rod/Pin Material: | Polyester |
General Specifications
| Weight: | 0.46 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
