Rexnord 1000FG Straight Running Flush Grid, Material: Green Low Friction Acetal, Width: 850mm, Pitch: 1in - 874.43.19
Part #:10148009
Catalog #:874.43.19
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Open Area (%): | 40 % | Series: | MatTop 1000 Series Chain |
| Product Type: | Straight Running | Chain Width (mm): | 850 mm |
| Belt Thickness (mm): | 8.7 mm | Chain Number: | 1000FG |
| Rod/Pin Material: | Polypropylene | Chain Material: | XLG |
| Chain Material Description: | Green Low Friction Acetal | Belt Thickness (in): | 0.34 in |
| Chain Pitch (in): | 1 in | Straight or Side-Flex: | Straight Running |
| Product Group: | Modular Plastic Belts | Product Line: | Plastic Modular Chain and Belt |
| Number of Positrack: | 2 | Chain Pitch (mm): | 25.4 mm |
| Chain Strength (N/m): | 22,000 N·m | Chain Width (in): | 33.46 in |
| Positrack Location: | Either | Chain Width Measurement System: | Metric |
| Chain Strength (lb/ft): | 1,508 lb/ft | Surface Type: | Flush Grid |
| Positrack: | True |
General Specifications
| Weight: | 0.13 KG | HTC: | 3926906090 |
| Country of Origin: | Mexico |
