Rexnord 1000FT Straight Running Solid Top, Material: Bright Lime-Green Dry PET Low Friction, Width: 85mm, Pitch: 1in - 873.84.10
Part #:10470173
Catalog #:873.84.10
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Chain Width (mm): | 85 mm | Surface Type: | Solid Top |
| Chain Width Measurement System: | Metric | Chain Strength (N): | 1,870 N |
| Chain Pitch (in): | 1 in | Belt Thickness (mm): | 8.7 mm |
| Positrack Location: | Center | Number of Positrack: | 2 |
| Chain Material: | Dry-PT | Chain Pitch (mm): | 25.4 mm |
| Product Type: | Straight Running | Open Area (%): | 0 % |
| Product Line: | Plastic Modular Chain and Belt | Straight or Side-Flex: | Straight Running |
| Chain Width (in): | 3.35 in | Product Group: | Modular Plastic Belts |
| Positrack: | True | Chain Material Description: | Bright Lime-Green Dry PET Low Friction |
| Chain Number: | 1000FT | Belt Thickness (in): | 0.34 in |
| Series: | MatTop 1000 Series Chain | Rod/Pin Material: | Polyester |
| Chain Strength (lb): | 420 lb |
General Specifications
| UPC: | 782935413888 | Weight: | 0.01 KG |
| HTC: | 39269097 | Country of Origin: | Netherlands |
