Rexnord 1005FT Straight Running Solid Top, Material: Green Low Friction Acetal, Width: 340mm, Pitch: 1in - 877.01.13
Part #:10200745
Catalog #:877.01.13
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Belt Thickness (in): | 0.5 in | Chain Material: | XLG |
| Chain Pitch (in): | 1 in | Chain Material Description: | Green Low Friction Acetal |
| Positrack Location: | Either | Chain Pitch (mm): | 25.4 mm |
| Belt Thickness (mm): | 12.7 mm | Chain Number: | 1005FT |
| Product Line: | Plastic Modular Chain and Belt | Product Group: | Modular Plastic Belts |
| Series: | MatTop 1005 Series Chain | Chain Width (mm): | 340 mm |
| Chain Strength (N/m): | 35,000 N·m | Open Area (%): | 0 % |
| Chain Width Measurement System: | Metric | Straight or Side-Flex: | Straight Running |
| Surface Type: | Solid Top | Chain Strength (lb/ft): | 2,399 lb/ft |
| Positrack: | True | Number of Positrack: | 2 |
| Chain Width (in): | 13.39 in | Product Type: | Straight Running |
| Rod/Pin Material: | Polyester |
General Specifications
| Weight: | 0.12 KG | HTC: | 3926906090 |
| Country of Origin: | Mexico |
