Rexnord 1005FT Straight Running Solid Top, Material: Green Low Friction Acetal, Width: 85mm, Pitch: 1in - 877.01.10
Part #:10295502
Catalog #:877.01.10
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Series: | MatTop 1005 Series Chain | Product Line: | Plastic Modular Chain and Belt |
| Chain Strength (N/m): | 35,000 N·m | Chain Pitch (mm): | 25.4 mm |
| Straight or Side-Flex: | Straight Running | Number of Positrack: | 2 |
| Chain Width Measurement System: | Metric | Open Area (%): | 0 % |
| Belt Thickness (mm): | 12.7 mm | Surface Type: | Solid Top |
| Chain Material: | XLG | Chain Strength (lb/ft): | 2,399 lb/ft |
| Chain Width (mm): | 85 mm | Product Group: | Modular Plastic Belts |
| Chain Material Description: | Green Low Friction Acetal | Rod/Pin Material: | Polyester |
| Chain Number: | 1005FT | Belt Thickness (in): | 0.5 in |
| Product Type: | Straight Running | Positrack Location: | Either |
| Chain Width (in): | 3.35 in | Positrack: | True |
| Chain Pitch (in): | 1 in |
General Specifications
| Weight: | 0.03 KG | HTC: | 3926906090 |
| Country of Origin: | Mexico |
