Rexnord 1505 RubberTop® Straight Running RubberTop®, Material: Beige High Temperature, Width: 12in, Pitch: 15mm - HTF1505-12
Part #:10029016
Catalog #:HTF1505-12
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Product Group: | Modular Plastic Belts | SG/RT Spacing (Pitches): | Every Pitch |
| Chain Pitch (in): | 0.59 in | Belt Thickness (mm): | 10.9 mm |
| Chain Width Measurement System: | Imperial | Product Type: | Straight Running |
| Rod/Pin Material: | Polyester | Chain Material: | HT |
| Series: | MatTop 1500 Series Chain | Chain Number: | 1505 RubberTop® |
| Straight or Side-Flex: | Straight Running | Number of SuperGrip/RubberTop Rows: | 1 Row |
| Belt Thickness (in): | 0.43 in | Chain Pitch (mm): | 15 mm |
| Chain Strength (lb/ft): | 540 lb/ft | Chain Material Description: | Beige High Temperature |
| Product Line: | Plastic Modular Chain and Belt | Chain Width (mm): | 304.8 mm |
| Chain Strength (N/m): | 7,879 N·m | Open Area (%): | 2 % |
| Chain Width (in): | 12 in | Surface Type: | RubberTop® |
General Specifications
| Weight: | 0.07 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
