Rexnord 1505 RubberTop® Straight Running RubberTop®, Material: Grey Tough Composite, Width: 12in, Pitch: 15mm - TCF1505-12
Part #:10029071
Catalog #:TCF1505-12
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Number of SuperGrip/RubberTop Rows: | 1 Row | Product Line: | Plastic Modular Chain and Belt |
| Chain Material: | GTC | Product Type: | Straight Running |
| Chain Strength (N/m): | 9,848 N·m | Belt Thickness (in): | 0.43 in |
| Chain Width (mm): | 304.8 mm | Chain Strength (lb/ft): | 675 lb/ft |
| Series: | MatTop 1500 Series Chain | Chain Pitch (mm): | 15 mm |
| Chain Number: | 1505 RubberTop® | Open Area (%): | 2 % |
| Chain Pitch (in): | 0.59 in | Straight or Side-Flex: | Straight Running |
| Chain Material Description: | Grey Tough Composite | Chain Width (in): | 12 in |
| Belt Thickness (mm): | 10.9 mm | Rod/Pin Material: | Acetal |
| Product Group: | Modular Plastic Belts | Chain Width Measurement System: | Imperial |
| SG/RT Spacing (Pitches): | Every Pitch | Surface Type: | RubberTop® |
General Specifications
| Weight: | 0.09 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
