Rexnord 1505 Straight Running Solid Top, Material: White High Temperature, Width: 12in, Pitch: 15mm - WHT1505-12
Part #:10029082
Catalog #:WHT1505-12
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Rod/Pin Material: | Polypropylene | Surface Type: | Solid Top |
| Chain Width (mm): | 304.8 mm | Belt Thickness (mm): | 8.7 mm |
| Straight or Side-Flex: | Straight Running | Product Group: | Modular Plastic Belts |
| Product Type: | Straight Running | Chain Pitch (in): | 0.59 in |
| Chain Width Measurement System: | Imperial | Chain Width (in): | 12 in |
| Product Line: | Plastic Modular Chain and Belt | Chain Number: | 1505 |
| Belt Thickness (in): | 0.34 in | Series: | MatTop 1500 Series Chain |
| Chain Material Description: | White High Temperature | Chain Pitch (mm): | 15 mm |
| Chain Material: | WHT |
General Specifications
| Weight: | 0.06 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
