Rexnord 1505 Straight Running Solid Top, Material: White High Temperature, Width: 3in, Pitch: 15mm - WHT1505-3
Part #:10029083
Catalog #:WHT1505-3
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Chain Width Measurement System: | Imperial | Product Line: | Plastic Modular Chain and Belt |
| Chain Material: | WHT | Product Group: | Modular Plastic Belts |
| Surface Type: | Solid Top | Chain Width (in): | 3 in |
| Chain Material Description: | White High Temperature | Rod/Pin Material: | Polypropylene |
| Chain Number: | 1505 | Chain Pitch (mm): | 15 mm |
| Chain Width (mm): | 76.2 mm | Series: | MatTop 1500 Series Chain |
| Belt Thickness (mm): | 8.7 mm | Product Type: | Straight Running |
| Chain Pitch (in): | 0.59 in | Straight or Side-Flex: | Straight Running |
| Belt Thickness (in): | 0.34 in |
General Specifications
| Weight: | 0.01 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
