Rexnord 1505DTS Straight Running DTS®, Material: Brown High Performance, Width: 4.5in, Pitch: 15mm - 81414111
Part #:10028389
Catalog #:81414111
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Straight or Side-Flex: | Straight Running | Positrack: | True |
| Product Type: | Straight Running | Chain Width (in): | 4.5 in |
| Belt Thickness (in): | 0.34 in | Positrack Location: | Center |
| Chain Pitch (in): | 0.59 in | Chain Number: | 1505DTS |
| Chain Strength (N): | 999 N | Series: | MatTop 1500 Series Chain |
| Product Group: | Modular Plastic Belts | Chain Width (mm): | 114.3 mm |
| Chain Material: | HP | Open Area (%): | 2 % |
| Chain Material Description: | Brown High Performance | Belt Thickness (mm): | 8.7 mm |
| Direction: | RH | Rod/Pin Material: | Polyester |
| Product Line: | Plastic Modular Chain and Belt | Chain Strength (lb): | 225 lb |
| Surface Type: | DTS® | Chain Width Measurement System: | Imperial |
| Number of Positrack: | 2 | Chain Pitch (mm): | 15 mm |
General Specifications
| Weight: | 0.04 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
