Rexnord 4706 Straight Running Flush Grid, Material: Tan Low Friction, Width: 24in, Pitch: 1.5in - LF4706-24
Part #:10029038
Catalog #:LF4706-24
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Product Type: | Straight Running | Open Area (%): | 22.1 % |
| Chain Pitch (mm): | 38.1 mm | Chain Strength (N/m): | 17,508 N·m |
| Belt Thickness (in): | 0.5 in | Belt Thickness (mm): | 12.7 mm |
| Rod/Pin Material: | Acetal | Product Group: | Modular Plastic Belts |
| Surface Type: | Flush Grid | Chain Pitch (in): | 1.5 in |
| Chain Number: | 4706 | Chain Width (mm): | 609.6 mm |
| Straight or Side-Flex: | Straight Running | Chain Material: | LF |
| Chain Strength (lb/ft): | 1,200 lb/ft | Chain Material Description: | Tan Low Friction |
| Chain Width (in): | 24 in | Series: | MatTop 4700 Series Chain |
| Product Line: | Plastic Modular Chain and Belt | Chain Width Measurement System: | Imperial |
General Specifications
| Weight: | 0.40 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
