Rexnord 5706 Straight Running Flush Grid, Material: Brown High Performance, Width: 4.5in, Pitch: 1.5in - 81416772
Part #:10028400
Catalog #:81416772
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Rod/Pin Material: | Polyester | Chain Number: | 5706 |
| Belt Thickness (in): | 0.5 in | Chain Strength (N): | 1,865 N |
| Straight or Side-Flex: | Straight Running | Chain Strength (lb): | 420 lb |
| Chain Material: | HP | Product Type: | Straight Running |
| Series: | MatTop 5700 Series Chain | Chain Pitch (mm): | 38.1 mm |
| Product Group: | Modular Plastic Belts | Chain Width (in): | 4.5 in |
| Chain Pitch (in): | 1.5 in | Chain Width (mm): | 114.3 mm |
| Product Line: | Plastic Modular Chain and Belt | Open Area (%): | 22.1 % |
| Chain Width Measurement System: | Imperial | Chain Material Description: | Brown High Performance |
| Surface Type: | Flush Grid | Belt Thickness (mm): | 12.7 mm |
General Specifications
| Weight: | 0.09 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
