Rexnord 5706 Straight Running Flush Grid, Material: Brown High Performance, Width: 7.5in, Pitch: 1.5in - 81416774
Part #:10028402
Catalog #:81416774
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Chain Width Measurement System: | Imperial | Chain Width (mm): | 190.5 mm |
| Chain Strength (lb): | 800 lb | Chain Number: | 5706 |
| Open Area (%): | 22.1 % | Chain Width (in): | 7.5 in |
| Series: | MatTop 5700 Series Chain | Chain Material: | HP |
| Chain Material Description: | Brown High Performance | Belt Thickness (in): | 0.5 in |
| Belt Thickness (mm): | 12.7 mm | Straight or Side-Flex: | Straight Running |
| Product Line: | Plastic Modular Chain and Belt | Chain Pitch (in): | 1.5 in |
| Rod/Pin Material: | Polyester | Surface Type: | Flush Grid |
| Chain Strength (N): | 3,552 N | Product Group: | Modular Plastic Belts |
| Product Type: | Straight Running | Chain Pitch (mm): | 38.1 mm |
General Specifications
| Weight: | 0.14 LB | HTC: | 3926909989 |
| Country of Origin: | Mexico |
