Rexnord 5935 Straight Running Solid Top, Material: Beige High Temperature, Width: 24in, Pitch: 0.75in - HT5935-24
Part #:10029002
Catalog #:HT5935-24
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Chain Number: | 5935 | Chain Width (mm): | 609.6 mm |
| Product Type: | Straight Running | Rod/Pin Material: | Polypropylene |
| Belt Thickness (in): | 0.34 in | Open Area (%): | 2.1 % |
| Chain Material Description: | Beige High Temperature | Surface Type: | Solid Top |
| Series: | MatTop 5930 Series Chain | Product Line: | Plastic Modular Chain and Belt |
| Product Group: | Modular Plastic Belts | Chain Strength (lb/ft): | 900 lb/ft |
| Straight or Side-Flex: | Straight Running | Chain Material: | HT |
| Chain Strength (N/m): | 13,131 N·m | Chain Width Measurement System: | Imperial |
| Chain Pitch (mm): | 19.1 mm | Chain Pitch (in): | 0.75 in |
| Belt Thickness (mm): | 8.7 mm | Chain Width (in): | 24 in |
General Specifications
| Weight: | 0.12 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
