Rexnord 5935 Straight Running Solid Top, Material: Tan Low Friction, Width: 3.75in, Pitch: 0.75in - LF5935-3.75
Part #:10029048
Catalog #:LF5935-3.75
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Straight or Side-Flex: | Straight Running | Product Line: | Plastic Modular Chain and Belt |
| Product Type: | Straight Running | Series: | MatTop 5930 Series Chain |
| Chain Number: | 5935 | Chain Material: | LF |
| Chain Width (in): | 3.75 in | Product Group: | Modular Plastic Belts |
| Chain Strength (lb/ft): | 900 lb/ft | Belt Thickness (mm): | 8.7 mm |
| Chain Strength (N/m): | 13,131 N·m | Chain Width (mm): | 95.3 mm |
| Chain Material Description: | Tan Low Friction | Surface Type: | Solid Top |
| Open Area (%): | 2.1 % | Chain Width Measurement System: | Imperial |
| Rod/Pin Material: | Polypropylene | Belt Thickness (in): | 0.34 in |
| Chain Pitch (in): | 0.75 in | Chain Pitch (mm): | 19.1 mm |
General Specifications
| Weight: | 0.03 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
