Rexnord 5935 Straight Running Solid Top, Material: Tan Low Friction, Width: 9in, Pitch: 0.75in - LF5935-9
Part #:10029053
Catalog #:LF5935-9
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Chain Pitch (mm): | 19.1 mm | Chain Width (mm): | 228.6 mm |
| Chain Material: | LF | Chain Strength (N/m): | 13,131 N·m |
| Belt Thickness (in): | 0.34 in | Straight or Side-Flex: | Straight Running |
| Product Group: | Modular Plastic Belts | Chain Width (in): | 9 in |
| Product Line: | Plastic Modular Chain and Belt | Chain Width Measurement System: | Imperial |
| Open Area (%): | 2.1 % | Chain Strength (lb/ft): | 900 lb/ft |
| Chain Material Description: | Tan Low Friction | Product Type: | Straight Running |
| Chain Pitch (in): | 0.75 in | Belt Thickness (mm): | 8.7 mm |
| Rod/Pin Material: | Polypropylene | Chain Number: | 5935 |
| Surface Type: | Solid Top | Series: | MatTop 5930 Series Chain |
General Specifications
| Weight: | 0.06 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
