Rexnord 5997 Straight Running Raised Rib, Material: Beige High Temperature, Width: 72in, Pitch: 2.25in - HT5997-72
Part #:10029013
Catalog #:HT5997-72
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Chain Strength (lb/ft): | 2,400 lb/ft | Surface Type: | Raised Rib |
| Chain Width (in): | 72 in | Product Line: | Plastic Modular Chain and Belt |
| Chain Pitch (mm): | 57.2 mm | Belt Thickness (mm): | 24.6 mm |
| Series: | MatTop 5990 Series Chain | Product Group: | Modular Plastic Belts |
| Chain Pitch (in): | 2.25 in | Chain Width Measurement System: | Imperial |
| Open Area (%): | 22.3 % | Chain Width (mm): | 1,828.8 mm |
| Straight or Side-Flex: | Straight Running | Chain Material Description: | Beige High Temperature |
| Chain Material: | HT | Chain Number: | 5997 |
| Product Type: | Straight Running | Belt Thickness (in): | 0.97 in |
| Rod/Pin Material: | Polypropylene | Chain Strength (N/m): | 35,016 N·m |
General Specifications
| Weight: | 2.48 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
