Rexnord 7703 Straight Running Low Backline Pressure, Material: Brown High Performance, Width: 21in, Pitch: 1in - 10324533
Part #:10324533
Catalog #:10324533
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Product Group: | Modular Plastic Belts | Series: | MatTop 7700 Series Chain |
| Product Line: | Plastic Modular Chain and Belt | Chain Number: | 7703 |
| Belt Thickness (mm): | 32.8 mm | Belt Thickness (in): | 1.29 in |
| Straight or Side-Flex: | Straight Running | Chain Material: | HP |
| Chain Material Description: | Brown High Performance | Chain Strength (N/m): | 43,041 N·m |
| Rod/Pin Material: | Polyester | Chain Width (mm): | 533.4 mm |
| Open Area (%): | 3 % | Chain Pitch (in): | 1 in |
| Chain Width Measurement System: | Imperial | Product Type: | Straight Running |
| Chain Width (in): | 21 in | Chain Strength (lb/ft): | 2,950 lb/ft |
| Surface Type: | Low Backline Pressure | Chain Pitch (mm): | 25.4 mm |
General Specifications
| Weight: | 0.74 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
