Rexnord 7703 Straight Running Low Backline Pressure, Material: Brown High Performance, Width: 27in, Pitch: 1in - 10324535
Part #:10324535
Catalog #:10324535
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Product Type: | Straight Running | Belt Thickness (in): | 1.29 in |
| Chain Width (in): | 27 in | Series: | MatTop 7700 Series Chain |
| Chain Material: | HP | Chain Pitch (mm): | 25.4 mm |
| Chain Strength (lb/ft): | 2,950 lb/ft | Chain Number: | 7703 |
| Chain Strength (N/m): | 43,041 N·m | Chain Material Description: | Brown High Performance |
| Product Line: | Plastic Modular Chain and Belt | Open Area (%): | 3 % |
| Surface Type: | Low Backline Pressure | Rod/Pin Material: | Polyester |
| Product Group: | Modular Plastic Belts | Chain Width (mm): | 685.8 mm |
| Chain Width Measurement System: | Imperial | Chain Pitch (in): | 1 in |
| Belt Thickness (mm): | 32.8 mm | Straight or Side-Flex: | Straight Running |
General Specifications
| Weight: | 0.32 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
