Rexnord 7705 Straight Running Solid Top, Material: Brown High Performance, Width: 3.25in, Pitch: 1in - 81416331
Part #:10028407
Catalog #:81416331
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Surface Type: | Solid Top | Chain Width (in): | 3.25 in |
| Chain Material Description: | Brown High Performance | Chain Strength (lb): | 685 lb |
| Rod/Pin Material: | Polyester | Chain Pitch (in): | 1 in |
| Belt Thickness (in): | 0.5 in | Straight or Side-Flex: | Straight Running |
| Open Area (%): | 3 % | Chain Number: | 7705 |
| Chain Material: | HP | Chain Width Measurement System: | Imperial |
| Product Group: | Modular Plastic Belts | Chain Strength (N): | 3,041 N |
| Product Type: | Straight Running | Series: | MatTop 7700 Series Chain |
| Belt Thickness (mm): | 12.7 mm | Chain Width (mm): | 82.6 mm |
| Chain Pitch (mm): | 25.4 mm | Product Line: | Plastic Modular Chain and Belt |
General Specifications
| Weight: | 0.06 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
