Rexnord 7705 Straight Running Solid Top, Material: Brown High Performance, Width: 36in, Pitch: 1in - HP7705-36
Part #:10028940
Catalog #:HP7705-36
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Rod/Pin Material: | Polyester | Chain Material: | HP |
| Belt Thickness (in): | 0.5 in | Chain Number: | 7705 |
| Product Line: | Plastic Modular Chain and Belt | Chain Width Measurement System: | Imperial |
| Belt Thickness (mm): | 12.7 mm | Chain Width (in): | 36 in |
| Straight or Side-Flex: | Straight Running | Chain Strength (lb/ft): | 2,950 lb/ft |
| Chain Material Description: | Brown High Performance | Chain Pitch (in): | 1 in |
| Series: | MatTop 7700 Series Chain | Chain Pitch (mm): | 25.4 mm |
| Chain Width (mm): | 914.4 mm | Chain Strength (N/m): | 43,041 N·m |
| Surface Type: | Solid Top | Product Group: | Modular Plastic Belts |
| Open Area (%): | 3 % | Product Type: | Straight Running |
General Specifications
| Weight: | 0.69 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
