Rexnord 7705 SuperGrip™ Straight Running SuperGrip™, Material: Beige High Temperature, Width: 30in, Pitch: 1in - 10383993
Part #:10383993
Catalog #:10383993
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Chain Width (mm): | 762 mm | Product Group: | Modular Plastic Belts |
| Belt Thickness (mm): | 17.6 mm | Chain Strength (lb/ft): | 1,800 lb/ft |
| Chain Strength (N/m): | 26,262 N·m | Chain Number: | 7705 SuperGrip™ |
| Chain Width (in): | 30 in | SG/RT Spacing (Pitches): | Every Pitch |
| Belt Thickness (in): | 0.69 in | Chain Width Measurement System: | Imperial |
| Number of SuperGrip/RubberTop Rows: | 1 Row | Open Area (%): | 3 % |
| Chain Pitch (in): | 1 in | Product Type: | Straight Running |
| Product Line: | Plastic Modular Chain and Belt | Rod/Pin Material: | Polypropylene |
| Chain Material: | HT | Series: | MatTop 7700 Series Chain |
| Surface Type: | SuperGrip™ | Straight or Side-Flex: | Straight Running |
| Chain Pitch (mm): | 25.4 mm | Chain Material Description: | Beige High Temperature |
General Specifications
| Weight: | 0.45 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
