Rexnord 7705DTS Straight Running DTS®, Material: Beige High Temperature, Width: 4.5in, Pitch: 1in - 81417951
Part #:10029109
Catalog #:81417951
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Chain Material: | HT | Open Area (%): | 3 % |
| Straight or Side-Flex: | Straight Running | Product Group: | Modular Plastic Belts |
| Chain Width (in): | 4.5 in | Direction: | LH |
| Chain Pitch (in): | 1 in | Belt Thickness (mm): | 12.7 mm |
| Chain Pitch (mm): | 25.4 mm | Product Line: | Plastic Modular Chain and Belt |
| Chain Width (mm): | 114.3 mm | Chain Material Description: | Beige High Temperature |
| Surface Type: | DTS® | Positrack Location: | Center |
| Number of Positrack: | 2 | Product Type: | Straight Running |
| Belt Thickness (in): | 0.5 in | Positrack: | True |
| Series: | MatTop 7700 Series Chain | Chain Strength (N): | 3,685 N |
| Chain Number: | 7705DTS | Rod/Pin Material: | Polypropylene |
| Chain Width Measurement System: | Imperial | Chain Strength (lb): | 830 lb |
General Specifications
| Weight: | 0.07 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
