Rexnord 7706 Straight Running Flush Grid, Material: Brown High Performance, Width: 4.5in, Pitch: 1in - 81416342
Part #:10028422
Catalog #:81416342
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Chain Width Measurement System: | Imperial | Product Group: | Modular Plastic Belts |
| Chain Number: | 7706 | Belt Thickness (mm): | 12.7 mm |
| Chain Material: | HP | Chain Pitch (in): | 1 in |
| Straight or Side-Flex: | Straight Running | Chain Material Description: | Brown High Performance |
| Rod/Pin Material: | Polyester | Surface Type: | Flush Grid |
| Chain Width (mm): | 114.3 mm | Open Area (%): | 8 % |
| Product Type: | Straight Running | Chain Strength (lb): | 1,025 lb |
| Chain Pitch (mm): | 25.4 mm | Chain Strength (N): | 4,551 N |
| Series: | MatTop 7700 Series Chain | Chain Width (in): | 4.5 in |
| Product Line: | Plastic Modular Chain and Belt | Belt Thickness (in): | 0.5 in |
General Specifications
| Weight: | 0.08 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
