Rexnord 7743 Straight Running Low Backline Pressure, Material: Brown High Performance, Width: 15in, Pitch: 1in - 10324682
Part #:10324682
Catalog #:10324682
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Open Area (%): | 3 % | Belt Thickness (mm): | 15.6 mm |
| Chain Number: | 7743 | Chain Material Description: | Brown High Performance |
| Product Line: | Plastic Modular Chain and Belt | Chain Width (in): | 15 in |
| Product Type: | Straight Running | Chain Pitch (in): | 1 in |
| Rod/Pin Material: | Polyester | Series: | MatTop 7700 Series Chain |
| Chain Width (mm): | 381 mm | Chain Strength (lb/ft): | 1,800 lb/ft |
| Belt Thickness (in): | 0.6125 in | Straight or Side-Flex: | Straight Running |
| Chain Strength (N/m): | 26,262 N·m | Chain Width Measurement System: | Imperial |
| Product Group: | Modular Plastic Belts | Chain Material: | HP |
| Chain Pitch (mm): | 25.4 mm | Surface Type: | Low Backline Pressure |
General Specifications
| Weight: | 0.31 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
