Rexnord 8505 Metric Width Straight Running Solid Top, Material: Brown High Performance, Width: 85mm, Pitch: 0.75in - 81416501
Part #:10028446
Catalog #:81416501
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Belt Thickness (mm): | 8.6 mm | Product Group: | Modular Plastic Belts |
| Chain Strength (lb): | 240 lb | Chain Strength (N): | 1,066 N |
| Belt Thickness (in): | 0.34 in | Chain Width (in): | 3.35 in |
| Positrack: | True | Product Line: | Plastic Modular Chain and Belt |
| Chain Width (mm): | 85 mm | Chain Material: | HP |
| Surface Type: | Solid Top | Chain Material Description: | Brown High Performance |
| Chain Pitch (in): | 0.75 in | Chain Pitch (mm): | 19.1 mm |
| Chain Number: | 8505 Metric Width | Positrack Location: | Center |
| Number of Positrack: | 2 | Chain Width Measurement System: | Metric |
| Straight or Side-Flex: | Straight Running | Rod/Pin Material: | Polyester |
| Open Area (%): | 4.1 % | Product Type: | Straight Running |
| Series: | MatTop 8500 Series Chain |
General Specifications
| Weight: | 0.03 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
