Rexnord 8505 RubberTop® Straight Running RubberTop®, Material: Beige High Temperature, Width: 33in, Pitch: 0.75in - 10324741
Part #:10324741
Catalog #:10324741
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Chain Strength (N/m): | 13,131 N·m | Chain Pitch (in): | 0.75 in |
| Belt Thickness (in): | 0.34 in | Open Area (%): | 4.1 % |
| Straight or Side-Flex: | Straight Running | Chain Width (in): | 33 in |
| Chain Pitch (mm): | 19.1 mm | Chain Width Measurement System: | Imperial |
| Chain Number: | 8505 RubberTop® | Number of SuperGrip/RubberTop Rows: | 1 Row |
| Chain Material Description: | Beige High Temperature | Product Group: | Modular Plastic Belts |
| Product Type: | Straight Running | Chain Strength (lb/ft): | 900 lb/ft |
| Belt Thickness (mm): | 8.6 mm | Rod/Pin Material: | Polypropylene |
| Chain Width (mm): | 838.2 mm | Surface Type: | RubberTop® |
| Product Line: | Plastic Modular Chain and Belt | Series: | MatTop 8500 Series Chain |
| Chain Material: | HT | SG/RT Spacing (Pitches): | Every Pitch |
General Specifications
| Weight: | 0.25 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
