Rexnord 8505 Straight Running Solid Top, Material: Brown High Performance, Width: 7.5in, Pitch: 0.75in - 81418211
Part #:10028445
Catalog #:81418211
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Straight or Side-Flex: | Straight Running | Product Line: | Plastic Modular Chain and Belt |
| Chain Strength (lb): | 625 lb | Surface Type: | Solid Top |
| Rod/Pin Material: | Polyester | Belt Thickness (in): | 0.34 in |
| Chain Material Description: | Brown High Performance | Chain Strength (N): | 2,775 N |
| Chain Pitch (in): | 0.75 in | Number of Positrack: | 2 |
| Belt Thickness (mm): | 8.6 mm | Open Area (%): | 4.1 % |
| Product Type: | Straight Running | Chain Width (mm): | 190.5 mm |
| Chain Material: | HP | Chain Number: | 8505 |
| Series: | MatTop 8500 Series Chain | Chain Pitch (mm): | 19.1 mm |
| Positrack Location: | Center | Positrack: | True |
| Product Group: | Modular Plastic Belts | Chain Width (in): | 7.5 in |
| Chain Width Measurement System: | Imperial |
General Specifications
| Weight: | 0.07 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
