Rexnord 8505 Straight Running Solid Top, Material: Silver Platinum Series™ X, Width: 18in, Pitch: 0.75in - 10295479
Part #:10295479
Catalog #:10295479
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Chain Width (in): | 18 in | Product Type: | Straight Running |
| Open Area (%): | 4.1 % | Series: | MatTop 8500 Series Chain |
| Chain Width Measurement System: | Imperial | Belt Thickness (in): | 0.34 in |
| Straight or Side-Flex: | Straight Running | Belt Thickness (mm): | 8.6 mm |
| Rod/Pin Material: | Polyester | Chain Number: | 8505 |
| Chain Pitch (in): | 0.75 in | Chain Strength (lb/ft): | 2,000 lb/ft |
| Chain Width (mm): | 457.2 mm | Chain Material Description: | Silver Platinum Series™ X |
| Product Line: | Plastic Modular Chain and Belt | Surface Type: | Solid Top |
| Chain Material: | PSX | Product Group: | Modular Plastic Belts |
| Chain Pitch (mm): | 19.1 mm | Chain Strength (N/m): | 29,180 N·m |
General Specifications
| Weight: | 0.17 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
