Rexnord 8505 Straight Running Solid Top, Material: White High Temperature, Width: 12in, Pitch: 0.75in - 81421241
Part #:10029102
Catalog #:81421241
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Chain Pitch (mm): | 19.1 mm | Chain Material Description: | White High Temperature |
| Product Type: | Straight Running | Chain Width Measurement System: | Imperial |
| Chain Number: | 8505 | Rod/Pin Material: | Polypropylene |
| Series: | MatTop 8500 Series Chain | Product Line: | Plastic Modular Chain and Belt |
| Surface Type: | Solid Top | Chain Width (in): | 12 in |
| Belt Thickness (mm): | 8.6 mm | Chain Width (mm): | 304.8 mm |
| Product Group: | Modular Plastic Belts | Belt Thickness (in): | 0.34 in |
| Straight or Side-Flex: | Straight Running | Chain Pitch (in): | 0.75 in |
| Chain Material: | WHT |
General Specifications
| Weight: | 0.08 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
