Rexnord 8505DTS Straight Running DTS®, Material: Silver Platinum Series™ X, Width: 4.5in, Pitch: 0.75in - 10295780
Part #:10295780
Catalog #:10295780
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Belt Thickness (mm): | 8.6 mm | Direction: | RH |
| Open Area (%): | 4.1 % | Number of Positrack: | 2 |
| Chain Strength (N): | 1,598 N | Chain Material: | PSX |
| Straight or Side-Flex: | Straight Running | Chain Pitch (mm): | 19.1 mm |
| Chain Width Measurement System: | Imperial | Chain Material Description: | Silver Platinum Series™ X |
| Surface Type: | DTS® | Positrack: | True |
| Chain Width (in): | 4.5 in | Product Type: | Straight Running |
| Chain Number: | 8505DTS | Product Line: | Plastic Modular Chain and Belt |
| Product Group: | Modular Plastic Belts | Chain Strength (lb): | 360 lb |
| Series: | MatTop 8500 Series Chain | Positrack Location: | Center |
| Chain Width (mm): | 114.3 mm | Rod/Pin Material: | Polyester |
| Chain Pitch (in): | 0.75 in | Belt Thickness (in): | 0.34 in |
General Specifications
| Weight: | 0.05 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
