Rexnord 1055 FTTAB Side-flexing Solid Top, Material: Brown High Performance, Width: 4.5in, Pitch: 1in - 749.10.40
Part #:10139070
Catalog #:749.10.40
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Straight or Side-Flex: | Side-flexing | Chain Material Description: | Brown High Performance |
| Flight Thickness (mm): | 12.7 mm | Flight Thickness (in): | 0.5 in |
| Chain Number: | 1055 FTTAB | Chain Strength (lb): | 425 lb |
| Chain Material: | HP | Surface Type: | Solid Top |
| Series: | TableTop 1055 Series Side-flexing Chain | Curve Retention Type: | TAB |
| Chain Strength (N): | 1,887 N | Chain Width (in): | 4.5 in |
| Chain Width (mm): | 114.3 mm | Rod/Pin Material: | Stainless Steel |
| Chain Pitch (mm): | 25.4 mm | Chain Width Measurement System: | Imperial |
| Chain Pitch (in): | 1 in |
General Specifications
| Weight: | 0.06 KG | HTC: | 3926906090 |
| Country of Origin: | United States of America |
