Rexnord 1673 Side-flexing Solid Top, Material: Brown High Performance, Width: 6in, Pitch: 1.5in - 10196352
Part #:10196352
Catalog #:10196352
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Chain Material Description: | Brown High Performance | Chain Number: | 1673 |
| Straight or Side-Flex: | Side-flexing | Flight Thickness (in): | 0.16 in |
| Chain Pitch (mm): | 38.1 mm | Chain Width Measurement System: | Imperial |
| Chain Width (mm): | 152.4 mm | Chain Width (in): | 6 in |
| Chain Material: | HP | Chain Strength (N): | 3,463 N |
| Curve Retention Type: | TAB | Flight Thickness (mm): | 4 mm |
| Surface Type: | Solid Top | Series: | TableTop 1673 Series Side-flexing Chain |
| Chain Strength (lb): | 780 lb | Chain Pitch (in): | 1.5 in |
| Base Chain Material: | Steel |
General Specifications
| Weight: | 0.25 LB | HTC: | 8431390010 |
| Country of Origin: | Mexico |
