Rexnord 1873TAB Side-flexing Solid Top, Material: Brown High Performance, Width: 6in, Pitch: 1.5in - 81414073
Part #:10144982
Catalog #:81414073
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Chain Material Description: | Brown High Performance | Base Chain Material: | Stainless Steel |
| Curve Retention Type: | TAB | Series: | TableTop 1873 Series Side-flexing Chain |
| Chain Pitch (mm): | 38.1 mm | Chain Material: | HP |
| Chain Width (mm): | 152.4 mm | Straight or Side-Flex: | Side-flexing |
| Flight Thickness (mm): | 4 mm | Chain Width Measurement System: | Imperial |
| Chain Strength (N): | 3,330 N | Flight Thickness (in): | 0.16 in |
| Chain Width (in): | 6 in | Chain Strength (lb): | 750 lb |
| Surface Type: | Solid Top | Chain Number: | 1873TAB |
| Chain Pitch (in): | 1.5 in |
General Specifications
| Weight: | 0.20 LB | HTC: | 8431390010 |
| Country of Origin: | Mexico |
