Rexnord 1873TAB SideGrip™ Side-flexing, Material: Heat Stabilized (Green), Width: 3.75in, Pitch: 1.5in - 81439311
Part #:10145845
Catalog #:81439311
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Chain Width (mm): | 95.3 mm | Chain Material Description: | Heat Stabilized (Green) |
| Gripper Material: | None | Chain Strength (lb): | 1,000 lb |
| Flight Thickness (in): | 0.16 in | Chain Material: | HS |
| Chain Strength (N): | 4,440 N | Surface Type: | SideGrip™ |
| Chain Pitch (in): | 1.5 in | Straight or Side-Flex: | Side-flexing |
| Gripper Color: | None | Curve Retention Type: | TAB |
| Base Chain Material: | Steel | Gripper Hardness: | None |
| Chain Width (in): | 3.75 in | Chain Number: | 1873TAB SideGrip™ |
| Chain Width Measurement System: | Imperial | Series: | TableTop 1873 Series Side-flexing Chain |
| Gripper Style: | None | Chain Pitch (mm): | 38.1 mm |
| Flight Thickness (mm): | 4 mm |
General Specifications
| Weight: | 0.17 LB | HTC: | 8431390010 |
| Country of Origin: | Mexico |
