Rexnord 1873TAB SideGrip™ Side-flexing, Material: Heat Stabilized (Green), Width: 3.75in, Pitch: 1.5in - 81447341
Part #:10146112
Catalog #:81447341
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Straight or Side-Flex: | Side-flexing | Chain Strength (N): | 3,330 N |
| Chain Pitch (in): | 1.5 in | Chain Width Measurement System: | Imperial |
| Gripper Material: | Neoprene | Chain Material Description: | Heat Stabilized (Green) |
| Gripper Style: | Finger Jaw | Chain Pitch (mm): | 38.1 mm |
| Chain Width (in): | 3.75 in | Chain Number: | 1873TAB SideGrip™ |
| Chain Width (mm): | 95.3 mm | Curve Retention Type: | TAB |
| Chain Material: | HS | Flight Thickness (mm): | 4 mm |
| Flight Thickness (in): | 0.16 in | Base Chain Material: | Stainless Steel |
| Series: | TableTop 1873 Series Side-flexing Chain | Gripper Color: | Black |
| Gripper Hardness: | 40 Shore A | Chain Strength (lb): | 750 lb |
| Surface Type: | SideGrip™ |
General Specifications
| Weight: | 0.38 LB | HTC: | 8431390010 |
| Country of Origin: | Mexico |
